MUENLED -SMD 3-in-1-PH6.6 Outdoor renten display
Product Details:
| Place of Origin: | china |
| Brand Name: | muenled |
| Certification: | CCC,FCC,ISO,9001,ROHS,CE |
| Model Number: | PH6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | US$ 500 |
| Packaging Details: | flijht case |
| Delivery Time: | 7 days |
| Payment Terms: | EXW,FOB,CIF |
| Supply Ability: | 10000PCS |
|
Detail Information |
|||
| Screen Dimension: | 640mm*640mm | Usage: | Outdoor |
|---|---|---|---|
| Tube Chip Color: | Full Color | Display Function: | Video |
| Pixels: | 6 | ||
Product Description
|
Parameters |
PH6.66 Outdoor SMD series |
|
Pixel Pitch |
6.66 mm |
|
Pixel Density |
22545/m² |
|
Pixel Configuration |
1R1G1B |
|
LED Standard |
SMD3535 |
|
Module Size |
320*160mm |
|
Module Resolution |
1152(Dots) |
|
Module Number |
2*4=8(Pcs) |
|
Cabinet Dimension |
640*640mm |
|
Cabinet Resolution |
1024(Dots) |
|
Cabinet weight |
17.5kg |
|
Brightness |
≥1800cd/m² |
|
Displays colors |
10.7Million color |
|
Protection Level |
IP 65 |
|
Control Mode |
Synchronous/Asynchronous |
|
Driving Method |
Constant driving 1/5scan |
|
Refresh Rate |
1000Hz |
|
Viewing Angle (H/V) |
H:120° V:120° |
|
The optimal viewing distance |
6-150mm |
|
Consumption |
Max.consumption 800w/m² Average.consumption 320w/m² |
|
LED Lamp Parameters |
(R) γ d:(625-628nm) IV:(1000mcd) (G) γ d:(523-525nm) IV:(2200mcd) (B) γ d:(470-472nm) IV:(500mcd) |
|
Comunication Type |
3G , WIFI, Cats ≤ 100m ,Multimode optical fiber ≤ 500m , Single Mode optical fiber ≤ 1500m |
| The above content is for reference | |
|
|
|
|
|
|
|
|
