Speadleader Seamless Switcher DVX802 DHL free shipping
Product Details:
| Place of Origin: | china |
| Brand Name: | muenled |
| Certification: | CCC,FCC,ISO,9001,ROHS,CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3PCS |
|---|---|
| Price: | US$ 1984 |
| Packaging Details: | wooden case |
| Delivery Time: | 7 days |
| Payment Terms: | EXW,FOB,CIF |
| Supply Ability: | 100PCS |
|
Detail Information |
Product Description
- Model: LCC-SpeedLeader-DVX802
- Shipping Weight: 6.5kg
- 122 Units in Stock
Speadleader Seamless Switcher DVX802 DHL free shipping
(seamless switcher mode, it would be equivalent of Extron ISS 506 + a led video processor. video wall mode, 3 screens video wall processor,can extend 3G-SDI or VID or DVI or VGA)
DVX802 is a mixing equipment of seamless switcher and video.wall processor. It support 8 video inputs and 3 outputs, at the same time it can extend one of the video inputs(3G-SDI/DVI/VGA/VID).
In seamless switcher mode, DXV802 support preview, program,and LED outputs. It can achieve the dynamic seamless switching among all the channels and LOGO insert. In Video Wall Mode, DVX802 support 3 splicing outputs, the splicing effect is the same as 3 LED video processor, without the external signal distributor. With high performance picture processing, simple and reliable operation, DVX802 is suitable for live portable stage and fixed installation.
| INPUT | ||||||
| Iterface | Quantity | Connector | Spec | |||
| DVI | 2 | DVI-1 |
DVI1.0,HDMI1.3
VESA Standard , PC to 1920x1200 , HD to 1080p
|
|||
| VGA | 2 | DB15 | VESA Standard , PC to 1920x1200 | |||
| VIDEO | 2 | BNC | PAL/NTSC/SECAM 1Vpp±3DB (0.7V Video+0.3v Sync ) 75 ohm 480i, 576i | |||
| HDMI | 1 | HDMI |
DVI1.0 , HDMI1.3
PC to 1920x1200 , HD to 1080p
|
|||
|
EXT
(Optional)
|
1 |
BNC/
VGA/DVI
|
Optional module:3G-SDI/Video/VGA/DVI
3G-SDI:1080p 60/50/30/25/24 1080i 60/50, 720p 60/50 625/525 line
|
|||
| PREVIEW(PREVIEW/OUTPUT1)/PROGRAM(OUTPUT2) | ||||||
| Quantity | VGAx1,DVIx1 | |||||
| Connector | DB15,DVI-I | |||||
| Standard | VESA Standard | |||||
|
Resolution
|
640x480@60Hz 1080p@60Hz 1366x768@60Hz 1680x1050@60Hz
720p@50Hz 1024x768@60Hz 1440x900@60Hz 1920x1200@60Hz
800x600@60Hz 1280x1024@60Hz 1536x1536@60Hz 1920x1280@60Hz
1080p@50Hz 1280x1920@60Hz 1600x1200@60Hz 2048x1152@60Hz
2304x1152@60Hz 2560x960@60Hz
|
|||||
| LED(OUTPUT3) | ||||||
| Connector | DVIx2 | |||||
| Connector | DVI-I | |||||
| Standard | DVI1.0 | |||||
|
Resolution
|
640x480@60Hz 1080p@60Hz 1366x768@60Hz 1680x1050@60Hz
720p@50Hz 1024x768@60Hz 1440x900@60Hz 1920x1200@60Hz
800x600@60Hz 1280x1024@60Hz 1536x1536@60Hz 1920x1280@60Hz
1080p@50Hz 1280x1920@60Hz 1600x1200@60Hz 2048x1152@60Hz
2304x1152@60Hz 2560x960@60Hz
|
|||||
| GENERAL | ||||||
| Weight | 4.7kg | |||||
| Dimensions | 6.5cm(H)x44cm(W)x32cm(D) | |||||
| Power supply | 100VAC – 240VAC 50/60Hz | |||||
| Power consumption | 40W | |||||
| Working temperature | 0°C～45°C | |||||
| MODLE | PRODUCT DESCRIPTION | |||||
| DVX802 | Standard models | |||||
| DVX802V | VGAx1 EXT module | |||||
| DVX802C | CVBSx1 module | |||||
| DVX802S | SDIx1 module | |||||
| DVX802D | DVIx1 module | |||||
Inquire for the Price and Solution >>> Latest offer
