Ball LED Screen Parameter
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | muenled |
| Certification: | CCC.FCC.UL.CE.ROSH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Packaging Details: | wooden case |
| Delivery Time: | 7-15DAYS |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 999PCS |
|
Detail Information |
|||
| NAME: | Ball LED Screen Parameter | PHONE: | +86 13510945503 |
|---|---|---|---|
| EMAIL: | MIKE@MLXLED.COM | ||
Product Description
 |
|
|
|
|
|
| Model Number | LW-BI8 | LW-BI10 | LW-BI6 | LW-BO10 | LW-BI5 |
| Pixel | 8mm | 10mm | 6mm | 10mm | 5mm |
| Pixel form | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Pixel Density | 15625pixels/㎡ | 10000pixels/㎡ | 27777pixels/㎡ | 10000pixels/㎡ | 40000pixels/㎡ |
| LED | SMD 3528 | SMD 3528 | SMD 3528 | SMD 3535 | SMD2121 |
| Scan | 1/8 Scan | 1/4 scan | 1/8 Scan | 1/2 Scan | 1/16 Scan |
| Brightness | ≥1300nit | ≥1100nit | ≥1600nit | 7500nit | ≥1800nit |
| Average PowerW/㎡ | 180 | 240W | 330 | 600W | 230 |
| Max Power W/㎡ | 370 | 480W | 650 | 1200W | 475 |
| Operating environment | Indoor | Indoor | Indoor | Outdoor | Indoor |
| Total resolution(dot) | 1152*328=377856 | 896X484=433664 | 2048X1184=2424832 | 1885X1665=3138525 | 4800*2024=9715200 |
| Total Size | Dia. 3M | Dia. 3M | Dia. 4M | Dia. 6M | Dia.7.2M |
| Total Square meter | 28.26㎡ | 28.26㎡ | 50.24㎡ | 113.094㎡ | 162.86㎡ |
| Net Weight | 990kg | 990kg | 1758kg | ≈9000Kg | 5705kg |
| Weight within Flight case | ≈1100kg | ≈1100kg | ≈1900kg | ≈9500KG | ≈6000kg |
| Refresh rate | 600HZ---5000HZ | 600HZ---5000HZ | 600HZ---5000HZ | 600HZ---3800HZ | 600HZ---5000HZ |
| Gray level | 4096---65536 | 4096---65536 | 4096---65536 | 4096---65536 | 4096---65536 |
| AC input voltage | 110-240V ±10% | 110-240V ±10% | 110-240V ±10% | 110-240V ±10% | 110-240V ±10% |
| Input power frequency | 50/60HZ | 50/60HZ | 50/60HZ | 50/60HZ | 50/60HZ |
| Brightness control level | 100leavel automatic or manual operation | ||||
| Temperature | 3200K---9500K adjustable | 3200K---9500K adjustable | 3200K---9500K adjustable | 3200K---9500K adjustable | 3200K---9500K adjustable |
| work temperature | —20℃～60℃ | —20℃～60℃ | —20℃～60℃ | —20℃～60℃ | —20℃～60℃ |
| work humidity | 10%～90% | 10%～90% | 10%～90% | 10%～90% | 10%～90% |
| Life span | ≥100000 hours | ≥100000 hours | ≥100000 hours | ≥100000 hours | ≥100000 hours |
| Mean Time Between Failure | ≥5000 hours | ≥5000 hours | ≥5000 hours | ≥5000 hours | ≥5000 hours |
| Discrete Blind Spot Rate | ＜0.0001 | <0.0001 | <0.0001 | <0.0001 | <0.0001 |
1>Modular small-unit and flexible design, makes possibility of more complicated shapes of video show.
2>Assembling screen with modules directly, saving time and effort, easy operation.
3>Magnet connection, apt to assemble & disassemble, maintain & replace.
4>No cabinet metal frame, drastically deducting the screen weight.
5>Strict quality control and long-term application experience verified the stablity and excellent performance.
6>Widely applied in shaped stage background/exhibition/shopping mall etc.
