Leo-4 Rental Led Display /Stage Background LED Video Wall Supply preferred muenled
Product Details:
| Place of Origin: | china |
| Brand Name: | muenled |
| Certification: | CCC,FCC,ISO,9001,ROHS,CE |
| Model Number: | Leo-4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10SQM |
|---|---|
| Price: | $1048 |
| Packaging Details: | flijht case |
| Delivery Time: | 7 days |
| Supply Ability: | >9999PCS |
|
Detail Information |
Product Description
Leo series
Indoor SMD Die-casting ultra slim cabinet(576*576)
1.Our products are conscientious works compared with others in LED display field. Can you guess the weight? 576mmX576mm only kg! Under the same size, it is the lightest die-casting aluminium cabinet in the history.
2.The products carefully orchestrated by engineers of muenled are absolutely nice. Besides the design of magnetic module, each module also use three insurance locks to reinforce and stabilize. Just turn on insurance locks, hold the small button and push out, the module is taken out easily. Replacing module only needs 3 seconds, improving more than 3 times efficiency .
3.Flywheel style fast lock of the die-casting aluminium cabinet work with the side pins and the u-shaped fittings to ensure faster installation and dismantling of the screen and ensure the flatness and tidiness .
4.High-definition, wide viewing angle, high gray scale and high refresh rate, let you enjoy the visual feast and experience the cost-effective products of muenled.
| Unit Module | NO. | Leo-4 Rental Led Display |
| Pixel pitch | 4mm | |
| Size of pixel | SMD2121(3 in1) | |
| Pixel configuration | 1R1G1B | |
| Size of block module | 288mm×288mm | |
| Resolution of module | 72×72 | |
| Density | 62500dots/m² | |
| Module power | 40W | |
| Cabinet | Cabinet material | Alu cabinet |
| Size of cabinet(l*h*t) | 576mm×576mm×95mm | |
| Weight of cabinet | 7KG | |
| Support hanging or not | yes | |
| Main Parameter | Best viewing distance | >4m |
| Best viewing angle | ≤140° | |
| Max power consumption | <600W/m² | |
| Colors | >16.7M | |
| Gray scale | 16bits | |
| Color temperature | 6500K | |
| Control method | Synchronization | |
| Driving device | Constant current | |
| Driving method | 1/16 scanning | |
| Frame frequency | 60Hz | |
| Refresh frequency | 1200-4800Hz | |
| Brightness | 600-900cd/m² | |
| Working voltage | AC220V/110V±10％ | |
| Working temperature | -20℃~50℃±10％ | |
| Out-of control point | <0.0001 | |
| Brightness Control | 256 grade | |
| Mtbf | 10,000Hours | |
| Life span | 100,000Hours |
As the figure shows, you can connect nearly all the video devices with your LED display. Video processor is a kind of devices that can convert the other video signal to DVI signal. And then the DVI signal will goes to the LED sender, and send from the CAT5 to the display.
For the further use, you can use the vidoe device like switcher, scaler and video matrix with our LED display.
