Product Details:

Place of Origin: CHINA
Brand Name: MUENLED
Certification: CE,FCC.
Model Number: P10

Payment & Shipping Terms:

Minimum Order Quantity: 10sqm
Packaging Details: wooden case
Delivery Time: 7-15day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 999sqm
Get Best Price Contact Now

Detail Information

Display Function: Video Usage: OUTDOOR
Pixels: 10mm Screen Dimension: Customized
LED Chip: SMD3535 Pixel Density: 10000 Dots/sqm
Brightness: 6500cd/sqm Refresh Rate: >1000HZ
Life-span: 100,000 Hours Scan: 1/4 Scan

Product Description

Video Description
00:00

00:28

Product Description
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 0
Setting Information
Name
rated voltage
AC110/220V
Power Consumption (Average)
160w/cabinet
Humidity
15%-85%
Refresh Rate
>1920Hz
Drive Mode
1/4Scan
Module Weight
39 kg
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 1

Well-known brand power supply , saving energy and high efficiency


All series outdoor Fixed adopt Meanwhile power supply, electro optic conversion ratio up to 82%, low heat dissipation and long
life span. Normal power supply electro optic conversion ratio is under 80%, and high heat dissipation, not stable, low cost.
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 2

Unique superior quality


One-piece sheet metal/iron die-casting box, front and rear maintenance structure design, waterproof, ultra-light cabinet design, unique and excellent quality, equipped with branded power supply, receiving card and other accessories, quality is guaranteed, installation and maintenance are safer.
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 3

Outdoor Fixed P10 LED

1: Pixel pitch: 10mm; cabinet size: 960×960mm
2: SMD 3535 LED; High brightness: 7500nits, adjustable brightness, high intensity.
3: Use standard processing technology to ensure that each row of lights is on the same horizontal line as each row of lights, and to ensure the consistency of light and a clear, stable picture.
4: The cabinet design is light, easy to maintain, IP65 high performance waterproof and dustproof.

Protection Rate IP65 and Module Style Design.

Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.



Ultra low power consumption, the first option for saving energy

The brightness of 7500 nits, the power consumption of 330W/sqm, and the power consumption of 1 kWh in three hours is 50% lower
than that of traditional panels. Excellent display performance, The first choice of millions of advertising operators.

LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 4
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 5

Wide Viewing Angle for Broader Reach

The display features a wide viewing angle of 120° horizontal and 160° in vertical which reaches more viewers. The picture quality remains seamless in all direction and at a distance, presenting all viewers the same highly quality outputs. This makes it suitable for large gathering.

High Refresh Rate
The P10 outdoor LED display is manufactured according to the latest technology dynamic scanning mode, which can provide higher
brightness and higher refresh rate. It has a high refresh rate of 1920Hz, independent RGB gamma adjustment, and can produce the
best quality output in the form of pictures, videos and texts, making pictures more real and clearer.
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 6
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 7
Rapid dynamic display
LED has a nanosecond response time, its lighting and extinguishing alternate time is extremely short, there is no afterglow effect of fluorescent display technology, so it can quickly respond to image changes, high dynamic definition, and has great inherent advantages.
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 8
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 9
Technical Parameter
Pixel Pitch
10mm
Type
SMD3535
Chip parameters
Red λd:(620-625nm) IV:(800-960mcd)
Chip parameters
Green λd:(520-525nm) IV:(1350-1650mcd)
Chip parameters
Blue λd:(470-475nm) IV:(330-400mcd)
Module Resolution
32×16=512(Dots)
Module Size
320×160mm
Pixel Density
10000 Dots/㎡
Cabinet Resolution
96×96=9216(Dots)
Cabinet Dimension(W*H*D)
960×960×130mm
Cabinets Material
Steel
Cabinet Weight
39kg
Brightness
≥7500cd/㎡
Viewing Angle
120(Horizontal),120(Vertical)
Nearest Viewing Distance
13m
Power Consumption (Max)
1000 w/㎡
Power Consumption (Average)
300 w/㎡
Refresh Rate
≥1000Hz
Input Voltage
AC110-220V±10%,50/60Hz
Grey Scale Levels
16bit
Brightness Adjustment
256 color levels,can be adjusted manually and automatically optional
Life-span
100,000 hours
Protection Level(front/back)
IP66/IP54
Working Temperature
-30℃~50℃
Humidity
15%~85%
Drive Mode/Driver Position
Constant driving 1/2 Scan,Combined diver board
Input Signal
AVI/MPG/MPEG/TXT.etc
Control Mode
Synchronization/Asynchronization
Certificate Control System
CE,ROHS,FCC,ISO9001,TUV Sending Card, Receiving Card,Receiving HUB
PC Operating System
Microsoft Windows 7, XP and Vista
CSoftware
LED Studio ( MIKE_TV-linsn )
Certificate
CE,ROHS,FCC,ISO9001,TUV
Communication Type
Net cable,3G,WIFI(Sold separately)
Control Card Input
DVI,USB,RJ45,HDMI(Sold separately)
Language
English,French,Japanese,Russian,Thai,Spanish,Polish,Italian,Portuguese,Turkish,Dutch,Greek,Bulgarian,Romanian,Arabic
Applications
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 10
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 11
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 12
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 13
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 14
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 15
Packing&delivering
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 16



Best After-sale Service



If your LED Screen is defected during warranty period, we will offer you free accessories to replace. Whenever you need us, we are always online for you. Our support staff will assist you for any problems. Feel free to contact us any time.



Company Information

MuenLED Co.,Ltd in Shenzhen China is a real factory who produce LED sign /display /billboard with high quality and competitive price.

Products: From P1.9- P16 / Taxi Roof Advertising / Rental Cabinets / LED truck/ transparent screen, etc.

Service: We are supplier of LED screens with excellent quality, and 2-year warranty for the products. Use Epistar chips for our products, sold to 20+ countries all over the world.Average lead time is less than 15 days. 12-year experience technical team to solve problems for you at anytime!

Please you do not hesitate to send us inquiries, you will get prompt attention.

Looking forward to hearing from you.

LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 17
Goods production - goods supply - pre-sale and after-sales service
1. We have the advantage of a full range of LED display production2: Goods supply from indoor and outdoor P10, P8, P6, P4, P3,P3.91, P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and give customers product performance introduction, as wellasproduct advantage analysis; According to the actual situation and the use of the situation, for the customer evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional training on the operation and maintenance of the led display system Display troubleshooting
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 18



Safety guarantee removes worries

The standard production process has undergone multiple quality tests, ensuring safety
1: Brand raw materials
2: Standardized production process
3: Whole process quality control
4: Multiple authentication
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 19
Certifications
LED Display Video Wall Advertising Sign P10 P8 P6 P5 HD Full Color Outdoor digital signage displays big tv screen panel 20
FAQ





muen led display Rental led Display muen led screen Price

muen led Rental muen led Lowest Price rental led lowest price





Q1. Can I have a sample order for led Screen?

A: Yes, we welcome sample order to test and check quality. Both for LED moduel or a whole screen



Q2. What about the lead time?

A:Order less than 50 square meter led time take 15 working days



Q3. Do you have any MOQ limit for led Screen order?

A: Low MOQ, 1 square meter or a moudle checking is available



Q4. How do you ship the goods and how long does it take to arrive?

A: We mostly accectp EXW trade term, but we can help you order and arrange shipping agent. It usually take 20-30 days by sea. a few days for customer clearance



Q5. How to proceed an order for led Screen?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places deposit for formal order.
Fourthly We arrange the production.



Q6. Is it OK to print my logo on led Display product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products
