Product Details:

Get Best Price Contact Now

Detail Information

Product Description

Specification
test 0
Setting Information
Name
Outdoor Fixed P10 LED
rated voltage
AC110-220V;50/60HZ
Power Consumption (Average)

300w/㎡
Humidity
15%-85%
Refresh Rate
>1000Hz
Drive Mode
1/2Scan
Module Weight
39kg
Certificate
CE, ROHS, FCC, ISO9001, TUV
Related Products
Product Description
test 7

&. Pixel Pitch: 10mm; Cabinet Size: 960×960mm
&. SMD 3535 LED; High brightness: 7500nits, and brightness adjustable,High intensity.
&. Standard processing technology to ensure each row and each column lamps at the same horizontal line, and ensure light consistency and clear, stability pictures.
&. SD to ensure large viewing angle, up to 120° horizontally and 120° vertically. Image no distortion, no color cast in any angle within this range.
& . Cabinet design lightweight, easy to maintain, IP65 high-performance waterproof and dust resistance.



Protection Rate IP65 and Module Style Design.

Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.

test 8
test 9



Well-known brand power supply , saving energy and high efficiency


All series outdoor Fixed adopt Meanwhile power supply, electro optic conversion ratio up to 82%, low heat dissipation and long life span. Normal power supply electro optic conversion ratio is under 80%, and high heat dissipation, not stable, low cost.

Ultra low power consumption, the first option for saving energy

7500 nits brightness with 330W/sqm power consumption, 50% less than the traditional panels. Excellent display performance, the first option for millions of advertising operators.




test 10
Specification
Pixel Pitch
10mm
Type
SMD3535
Chip parameters
Red λd:(620-625nm) IV:(800-960mcd)
Chip parameters
Green λd:(520-525nm) IV:(1350-1650mcd)
Chip parameters
Blue λd:(470-475nm) IV:(330-400mcd)
Module Resolution
32×16=512(Dots)
Module Size
320×160mm
Pixel Density
10000 Dots/㎡
Cabinet Resolution
96×96=9216(Dots)
Cabinet Dimension(W*H*D)
960×960×130mm
Cabinets Material
Steel
Cabinet Weight
39kg
Brightness
≥7500cd/㎡
Viewing Angle
120(Horizontal),120(Vertical)
Nearest Viewing Distance
13m
Power Consumption (Max)
1000 w/㎡
Power Consumption (Average)
300 w/㎡
Refresh Rate
≥1000Hz
Input Voltage
AC110-220V±10%,50/60Hz
Grey Scale Levels
16bit
Brightness Adjustment
256 color levels,can be adjusted manually and automatically optional
Life-span
100,000 hours
Protection Level(front/back)
IP66/IP54
Working Temperature
-30℃~50℃
Humidity
15%~85%
Drive Mode/Driver Position
Constant driving 1/2 Scan,Combined diver board
Input Signal
AVI/MPG/MPEG/TXT.etc
Control Mode
Synchronization/Asynchronization
Certificate Control System
CE,ROHS,FCC,ISO9001,TUV Sending Card, Receiving Card,Receiving HUB
PC Operating System
Microsoft Windows 7, XP and Vista
CSoftware
LED Studio ( MIKE_TV-linsn )
Certificate
CE,ROHS,FCC,ISO9001,TUV
Communication Type
Net cable,3G,WIFI(Sold separately)
Control Card Input
DVI,USB,RJ45,HDMI(Sold separately)
Language
English,French,Japanese,Russian,Thai,Spanish,Polish,Italian,Portuguese,Turkish,Dutch,Greek,Bulgarian,Romanian,Arabic
Packing & Delivery
test 11
Certifications
test 12
Company Information

MUENLED Co.,Ltd in Shenzhen China is a real factory who making LED sign /display /billboard
with high quality and competitive price.
Products:
From P1.9- P31.25 / Taxi Roof Advertising / Rental Cabinets / LED truck/ Strip screen,etc.
Service:
We are supplier of LED screens with excellent quality, and 3-year warranty for the products.
Use Epistar chips for our products, sold to 20+ countries all over the world.Average lead time is less than 15 days.
A 12 years experience technical team to solve problems for you anytime!
If you do not hesitate to send us any of your inquiries,it`s will get prompt attention.
Looking forward to hearing from you.
