C&Light Q7 HD LED Sender supports DVI and HDMI video input
Product Details:
| Place of Origin: | china |
| Brand Name: | muenled |
| Certification: | CCC,FCC,ISO,9001,ROHS,CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3PCS |
|---|---|
| Price: | US$ 709 |
| Packaging Details: | wooden case |
| Delivery Time: | 7 days |
| Payment Terms: | EXW,FOB,CIF |
| Supply Ability: | 100PCS |
|
Detail Information |
Product Description
- Model: LCC-CLight-Q7
- Shipping Weight: 3kg
- 15 Units in Stock
- Manufactured by: ColorLight
C&Light Q7 HD LED Sender supports DVI and HDMI video input
Brief Introduction:
Q7 HD Sender is specially designed for large LED displays. Q7 supports DVI and HDMI video input, the maximum input resolution of 2560 * 1536 pixels, and contains four Ethernet port outputs. So that a single Q7 can support the large LED displays with any resolutions that the total quantity of pixels is less than 2621440 pixels, e.g. 2560*1024, the width up to 2560 pixels, or the height up to 1536 pixels. Q7 also supports audio inputs, which is used to transmit the audio to the Multifunction Card, so that the audio can be output on the side of the display. Meanwhile, Q7 also has many useful functions, such as playing the default image on display when there is no signal, on-board test function, on-board temperature detection function, etc.
Features:
• Single card supports a maximum resolution of 2560 * 1536 pixels, such as 1920*1080, 1920*640, 1600*768, 1280*1024, 1280*720, 1024*768, etc.
• Four Gigabit Ethernet ports output. Each port can control an area within 655360 pixels.
• Single card supports LED display with any resolutions that the total quantity of pixels is less than 2621440 pixels, e.g. 2560*1024,1700*1536, the width up to 2560 pixels, or the height up to 1536 pixels.
• Supports audio input.
• USB interface for controlling and configuring.
• Supports standard network transmission equipment, such as Fiber Converter, Gigabit Switch.
• Supports commissioning and aging test the whole LED display without PC.
• Supports adjusting brightness of 16 levels by the buttons on the front panel, that the adjustment can be effective immediately and saved automatically.
• Supports Time Management Function that can follow up and manage the project process.
• No need to configure the display again when you replace the receiving cards or cabinets.
• Supports presetting images that can be showed on the LED display if there is no video input.
